Ubiquiti Access Point U6 Mesh
Ubiquiti | SKU:
U6-MESH-US
Regular price
$179.00
Unit price
Ubiquiti Access Point U6 Mesh is backordered and will ship as soon as it is back in stock.
Care information
Care information
Display general product information or specific product information using metafields.
Delivery and Shipping
Delivery and Shipping
We ship using the Common Carriers in the USA.
Ubiquiti Access Point U6 Mesh
Regular price
$179.00
Unit price
Ubiquiti Access Point U6 Mesh is backordered and will ship as soon as it is back in stock.
Description
Description
Sleek, indoor/outdoor WiFi 6 AP with 6 spatial streams designed for mesh applications.
Key Features
- WiFi 6
- 6 spatial streams
- 140 m² (1,500 ft²) coverage
- 250+ connected devices
- Powered using PoE
- GbE uplink
- Versatile tabletop, wall, and pole mounting
- Weatherproof (outdoor exposed)*
- *Weatherproof when installed LED side up with the included pole/wall mount accessory.
Overview
Dimensions
⌀48.5 x 159.5 mm
(⌀1.9 x 6.3")
WiFi Standard
WiFi 6
Spatial Streams
6
Coverage Area
140 m² (1,500 ft²)
Max. Client Count
250+
Uplink
GbE
Mounting
Wall, Pole
(Mounts Included)
Weatherproofing
IPX5
Power Method
PoE
Performance
MIMO
5 GHz
4 x 4 (DL/UL MU-MIMO)
2.4 GHz
2 x 2 (DL/UL MU-MIMO)
Max. Data Rate
5 GHz
4.8 Gbps (BW160)
2.4 GHz
573.5 Mbps (BW40)
Antenna Gain
5 GHz
5 dBi
2.4 GHz
3 dBi
Max. TX Power
5 GHz
26 dBm
2.4 GHz
22 dBm
Max. BSSIDs
8 per Radio
Supported Data Rates
802.11ax (WiFi 6)
7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
802.11ac (WiFi 5)
6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11n
6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
Features
Wireless Meshing
Band Steering
802.11v BSS Transition Management
802.11r Fast Roaming
802.11k Radio Resource Management (RRM)
Advanced Radio Management
Passpoint (Hotspot 2.0)
Captive Hotspot Portal
Custom Branding Landing Page
Voucher Authentication
Payment-Based Authentication
External Portal Server Support
Password Authentication
Guest Network Isolation
Private Pre-Shared Key (PPSK)
WiFi Speed Limiting
Client Device Isolation
WiFi Schedules
RADIUS over TLS (RadSec)
Dynamic RADIUS-assigned VLAN
Hardware
Max. Power Consumption
13W
Includes PoE Adapter
Supported Voltage Range
44–57V DC
Networking Interface
(1) GbE RJ45 port
Weight
400 g (14.1 oz)
Management
Ethernet
Enclosure Material
Polycarbonate, aluminum
Mount Material
Polycarbonate
LEDs
System
White/Blue
Channel Bandwidth
HT 20/40, VHT 20/40/80/160, HE 20/40/80/160 (MHz)
NDAA Compliant
Certifications
CE, FCC, IC, SRRC, Anatel: 02111-22-08356
Operating Frequency
US/CA:
2400 - 2472 MHz
U-NII-1: 5150 - 5250 MHz
U-NII-2A: 5250 - 5350 MHz
U-NII-2C: 5470 - 5725 MHz
U-NII-3: 5725 - 5850 MHz
Worldwide:
2400 - 2483.5 MHz
5150 - 5850 MHz
Ambient Operating Temperature
-30 to 60° C (-22 to 140° F)
Ambient Operating Humidity
5 to 95% noncondensing
Software
Application Requirements
UniFi Network
Version 6.0.45 and later
